Getweld Automated PAW+TIG Longitudinal Seam Welders are designed for material with higher thickness over 5mm. Esp. for stainless steel. Full-penetration welding with PAW as base, then adopts Auto. TIG welding fill and cover welding seam.
No need groove with material, low consumption of wire feeding, high welding efficiency…are features of this seam welder.
Gas requirements: PAW: 100%Ar +2.5%H2; TIG: 100%Ar+5-10%H2
| Specifications | |
|---|---|
| Welding material | Getweld Automated Longitudinal Seam Welders (PAW+TIG Dual-use) are designed for straight line, linear welding applications. PAW is used as base welding with full-penetration. TIG welding is used as filling and covering. A wide variety of materials can be welded, including stainless steel, carbon steel, steel alloy, copper… |
| Applications | Tubes with Dia. above 400mm LNG\LPG Cylinder-Both inner and outer cylinder Middle and Large-scale cryogenic storage tank-Both inner and outer tank |
| Material | Stainless steel Carbon steel Galvanized steel Thickness of material: 2.0-8mm Dia. range of cylinder: 400-2000mm Length of cylinder: L≤4500mm Large-scale cryogenic storage tank should be designed on site. |
| Examples of welding products |    |
